Coreless Induction Metal Melting Furnace with Steel Shell
Heavy-Duty Melting for Foundries & Steel Mills
The Topyro steel shell induction melting furnace is a heavy-duty coreless induction furnace engineered for continuous, high-volume melting of steel, cast iron, copper, and aluminum. Its steel shell is combined with a laminated silicon-steel magnetic yoke that contains and directs the magnetic field into the charge — delivering higher melting efficiency, lower stray field loss, and greater structural rigidity than aluminum shell designs.
Built on Topyro's IGBT/SCR medium-frequency power platform, the furnace achieves temperatures up to 2000°C with fast melting cycles and precise temperature control. Capacities range from 0.5T to 30T, making it the preferred choice for foundries, steel plants, and non-ferrous melting operations that run around the clock.
As a factory-direct manufacturer, we handle engineering, fabrication, installation, commissioning, and operator training — you receive a working melting furnace, not just a machine.
Key Features of the Steel Shell Induction Melting Furnace
- Magnetic yoke design — laminated silicon-steel yokes contain the magnetic field, directing energy into the charge for up to 20% higher efficiency than yokeless designs.
- Heavy-duty steel shell — maximum structural rigidity and safety, built for 24/7 continuous production.
- IGBT/SCR medium-frequency power supply — high power factor, fast melting, and precise temperature control with reduced grid impact.
- Electromagnetic stirring — uniform bath temperature and composition for consistent casting quality.
- Hydraulic tilting system — smooth, controlled pouring with manual backup for safety.
- CE-certified & export-ready — machinery test reports and full documentation provided with every shipment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Capacity | 0.5T – 30T (custom) |
| Max temperature | up to 2000°C |
| Power | 100kW – 10,000kW (custom) |
| Frequency | 200 – 2500 Hz |
| Power supply type | IGBT / SCR, series or parallel circuit |
| Shell construction | Steel shell + magnetic yoke |
| Tilting | Hydraulic tilting with manual backup |
| Cooling system | Closed-loop water cooling (open/closed cooling tower optional) |
| Control system | PLC + HMI with status monitoring and alarm |
Applications
The steel shell induction melting furnace serves foundries, mini steel plants, and non-ferrous smelters across the Middle East, Southeast Asia, Africa, Russia, and Latin America. Typical users include gray and ductile iron foundries upgrading from cupola melting, steel plants melting scrap for billets, and copper or aluminum processors running continuous casting lines around the clock.
Turnkey Supply & After-Sales Support
- Custom engineering according to your plant layout and product mix
- Worldwide shipping, installation, and commissioning by our engineers
- Operator training and spare parts support for the life of the furnace
- 1-year warranty with machinery test reports included
Contact us with your capacity and product requirements for a customized furnace quotation.
